WP-H1650

WP-H1650 is a heat-resistant epoxy resin system. Suitable for bicycle wheels, car exhaust pipes, and various industrial applications that require heat resistance. Appropriate resin fluidity is suitable for the blowing molding technology of bicycle wheel rims, and the molded products can achieve good surface quality. According to the characteristics of the customer's equipment, it can be molded under various conditions between 125~175 degree , and if necessary, the maximum heat resistance can be achieved through an independent (demolding) curing process.

1. High Tg resin system: 170 degree Tg (tested by DSC)

2. Flow resistance/excellent surface quality suitable for mold forming

3. Multiple molding conditions can be used flexibly (post curing/no post curing); If you want to improve production efficiency, you can try "curing after demolding"

4. Can be stored for four weeks at room temperature

		WP-H1650
ASTM D790		160(2.2x104)
ASTM D790		3250(4.7x105)
ASTM D256,Unnotched Izod	KJ/m2	23

WP-L5100

Vacuum bag forming (low-temperature curing): Large structures such as ships (kayaks, yachts, etc.), wind turbine blades, etc.

1. Rapid curing (10 minutes @ 150 degree , 20 minutes @ 130 degree )

2. Low temperature molding may occur (>80 degree or above)

3. Independent post curing can improve heat resistance and mechanical properties.

4. Shelf life: 3 weeks at 25 degree

		WP-H1650
ASTM D790		136(2.0x104)
ASTM D790		2720(4.0x105)
ASTM D256,Unnotched Izod	KJ/m2	25

WP-R2300

WP series 125 degree curing epoxy resin

		WP-R1200	WP-R2300	WP-R5600
ASTM D790		142(2.06x104)	140(2.03x104)	137(1.99x104)
ASTM D790		2950(4.28x105)	2850(4.13x105)	2750(3.99x105)
ASTM D256,	KJ/m2	31	34	37

WP-S5000

WP-S5000 is a 125 degree cured epoxy resin system that can achieve the optimal balance between static properties (bending/compression strength and elasticity) and dynamic properties (impact strength, fatigue characteristics). Widely used in the manufacturing of high-performance sports equipment such as bicycles, ice hockey sticks, tennis rackets, golf clubs, etc. By adjusting the flowability of the resin, viscosity and flexibility suitable for the prepreg operation process can be obtained. Minimize differences in usage characteristics (viscosity and softness) with temperature changes. WP-S5000 can be stored for four weeks at room temperature and for one year at minus 18 degree

		WP-S5000
ASTM D790		144(2.1x104)
ASTM D790		3158(4.58x105)
ASTM D256,Unnotched Izod	KJ/m2	22

WP-S1000

WP-S1000 is a 125 degree cured epoxy resin system, which is the most suitable resin system for pipe products formed by rolling tubes (such as fishing rods, golf clubs, arrow shafts, camera tripods, pipe products, etc.).

WP-S1000 is a resin system produced through the hot melt epoxy resin process. The characteristic of WP-S1000 resin is that it has good flowability during molding, which can be used to produce products with low porosity and high fiber content.

WP-S1000 resin also has viscosity and softness suitable for the tube rolling process, with the best production operability, and can be stored for about four weeks at room temperature.

1. Low viscosity standard epoxy resin for pipe product molding

2. Good fluidity of resin: can produce products with high fiber content

3. Hot melt resin/solvent-free: minimizes pores, reflecting the highest quality

4. Optimal prepreg operability: possessing the most suitable viscosity and softness for pipe products

5. Reasonable price and excellent quality

6. Shelf life: Approximately four weeks at 25 degree

		WP-S1000
ASTM D790		155(2.2x10⁴)
ASTM D790		2900(4.2x10⁵)
ASTM D256,Unnotched Izod	²	28

WP-S3000

WP-S3000 is a 125 degree cured epoxy resin system that can achieve the optimal balance between static properties (bending/compression strength and elasticity) and dynamic properties (impact strength, fatigue characteristics). Widely used in the manufacturing of high-performance sports equipment such as bicycles, ice hockey sticks, tennis rackets, golf clubs, etc. By adjusting the flowability of the resin, viscosity and flexibility suitable for the prepreg operation process can be obtained. Minimize differences in usage characteristics (viscosity and softness) with temperature changes. WP-S3000 can be stored for four weeks at room temperature and for one year at minus 18 degree

1. Various mold forming processes and specialized medium viscosity standard epoxy resin for pipe product forming

2. Optimal balance between static and dynamic properties: high impact strength and high bending strength

3. Excellent resin fluidity

4. Hot melt resin/solvent-free: minimizes pores, reflecting the highest quality

5. Best prepreg operability: Good flexibility, minimal differences in resin properties with temperature changes

6. Reasonable price and excellent quality

7. Shelf life: Approximately 4 weeks at 25 degree

		WP-S3000
ASTM D790		151(2.2x10⁴)
ASTM D790		2870(4.2x10⁵)
ASTM D256,Unnotched Izod	²	29
